SC620I | APC Smart-UPS SC 620VA 230V 390W/DB9/RS232/2Yr Wty

SC620I | APC Smart-UPS SC 620VA 230V 390W/DB9/RS232/2Yr Wty

Sale!

$443.90 inc GST

Out of stock

See this Product at BUZY Networks

THIS STORE IS MOVING TO BUZY.COM.AU.

BUZY Networks is our new home on the web, where you’ll get the same great service and advice from the team that behind Ubiquiti Store Australia since 2017. More info.
Sale!

Product Description

Product Description

Output
• Output power capacity: 390 Watts / 620 VA
• Max Configurable Power (Watts): 390 Watts / 620 VA
• Nominal Output Voltage: 230V
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 47 – 53 Hz for 50 Hz nominal, 57 – 63 Hz for 60 Hz nominal
• Topology: Line Interactive
• Waveform type: Stepped approximation to a sinewave
• Output Connections:
• (1) IEC 320 C13 (selector_surgetitle)
• (3) IEC 320 C13 (Battery Backup)
• Transfer Time: 2ms typical

Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections: IEC-320-C14 inlet
• Input voltage range for main operations: 195 – 265 V

Batteries Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time: 5.5 hour(s)
• Replacement Battery: RBC4
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 132
• Runtime: View Runtime Graph View Runtime Chart
• Efficiency: View Efficiency Graph

Communications Management
• Interface Port(s): DB-9 RS-232
• Control panel: LED status display with On Line: On Battery: Replace Battery and Overload indicators
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
• Emergency Power Off (EPO): N/A

Surge Protection and Filtering
• Surge energy rating: 320 Joules
• Data Line Protection: RJ-45 Modem/Fax/DSL/10-100 Base-T protection
• Filtering: Full time multi-pole noise filtering: 0.7% IEEE surge let-through: zero clamping response time: meets UL 1449

Physical
• Maximum Height: 168, 16.8 cm
• Maximum Width: 119, 11.9 cm
• Maximum Depth: 375, 37.5 cm
• Net Weight: 12.27 kg
• Shipping weight: 13.18 kg
• Shipping Height: 318, 31.8 cm
• Shipping Width: 262, 26.2 cm
• Shipping Depth: 508, 50.8 cm
• Color: Grey

Environmental
• Operating Environment: 0 – 40 °C
• Operating Relative Humidity: 0 – 95 %
• Operating Elevation: 0-3000 meters
